ReefLED® 160S

Deeper. Wider. Stronger.

Red Sea’s ReefLED® series is the result of years of research into the lighting needs of corals in artificial environments.



Uniquely designed with a light intensity and spectrum that is 100% utilized by the corals, ReefLED lights are 100% reef-safe & 100% REEF-SPEC®, providing optimal growth, vivid colors, and an elegant gentle shimmer throughout the aquarium.



The ReefLED® 160S is the big brother of the ReefLED series, making corals stand out and sing in even deeper and wider tanks.



The ReefLED 160S combines 160W of REEF-SPEC & Reef-Safe LED light with a patent-pending stadium-shaped lens, creating a beautiful, homogeneous spread throughout an aquarium of 80cm / 32’’ in all three directions. Multiple units can be mounted 75 cm / 30” apart while still guaranteeing a visual uniformity of light across the length of the entire aquarium. Only two units are required for a 150cm / 6″ long tank, or three units for a 225cm / 7.5″ long tank. The 160S is therefore the smart choice for bigger tanks.



At the heart of the unit is a single, compact LED array, providing 160W of REEF-SPEC & Reef-Safe LED light. It includes 140W of multi-wavelength 23,000 Kelvin REEF-SPEC Blue (a proprietary blend of blue, violet and ultraviolet LEDs), together with 20W of 9,000 Kelvin White, and a separate 3W channel for moonlight. This array enables a wide range of REEF–SPEC light that will please both you and your corals.



The ReefLED 160S is also equipped with a built-in Wi-Fi that allows total control via ReefBeat smart aquarium app (which controls all Red Sea devices). The app includes pre-set lighting programs, along with additional features such as sunrise/sunset effects, lunar cycle moon light, random clouds and even an acclimation program for new installations.

Home
/
Hardware
/
ReefLED® Series
/
ReefLED® 160S
Reviews
Manual
FAQ
Spare parts

Features

  • REEF-SPEC® light output for optimal coral growth and coloration
  • Homogeneous light with a gentle shimmer
  • Reef-safe dual-channel color setting plus dedicated moonlights
  • ReefBeat® app for easy set-up, operation, monitoring & notifications
  • Anti-glare recessed lens and clip-on visor
  • Pat-pending stadium-shaped lens provides homogeneous light spread
  • Units can be mounted up to 75cm / 30″  apart for superior coverage
Optimal coral growth
Reef safe
Easy setup
App operated
Stadium lens

Reef-safe PAR distribution

ReefLED is Reef-safe as it provides ideal PAR values throughout the aquarium, without hotspots or areas with insufficient light for coral growth. The PAR distribution map shows the actual PAR levels as they vary throughout the cross-section of the aquarium.

ReefLED Programs | PAR vs. PUR

Using PAR measurements only to determine light quality or compatibility of a specific light unit for coral photobiology can be misleading. The PAR measurement was developed to measure the Photosynthetic Active Radiation of plants that is within the visible light region (400 -700 nm).



The Photosynthetic Utilized Radiation or PUR that is relevant for optimal Zooxanthellae photosynthesis is between 360- 480 nm which starts outside the range of visible light (measured by PAR meters) in the UV region and continues into the blue part of the visible light range.



PUR cannot be measured directly but must be calculated by isolating the PUR wavelength intensity data for each wavelength from radio-spectrometer analysis.



The REEF-SPEC Blue channel of the ReefLED is 100% PUR so for this channel the PUR will actually be slightly higher than the measured PAR due to the UV wavelengths that the PAR meter cannot detect.



The 8000K White of the ReefLED has a strong blue peak in the PUR spectrum as well as wavelengths across the whole visible light spectrum and therefore has a PUR of 45% of its PAR.



The actual PUR output of the ReefLED will vary according to the combined settings of the REEF-SPEC Blue and White channels.

ReefLED 160S Specifications

Superior coverage

Recommended usage by tank size

ReefBeat app

  • One interface for all of Red Sea’s smart devices.
  • Easy set-up and operation.
  • On-line monitoring and notifications.

App features

Red Sea Insights

Lighting Insights | Episode 1 Learn about the 4 main reasons that make lighting so important in your reef aquarium. Explore
Lighting Insights | Episode 2 What makes aquarium lighting Reef-Safe? What are the criteria that provide the optimal conditions for corals to flourish? What is Red Sea's REEF-SPEC? Explore
Lighting Insights | Episode 3 Join us as we bust some myths about PAR readings and cast a light on a very important range of the light spectrum, that's still "in the dark". Explore
Lighting Insights | Episode 4 Learn about light versus dark periods and the relationship between spectrum, intensity, and photoperiod. Explore
